Tubesheet drilling in progress
Solution

Heat Exchanger Bundle Supply

Buying a bundle's parts from three suppliers means three interpretations of one drawing. This is the route where tube, fin and tube plate come from the same document and the same works.

Get A Custom Solution See the Process
Process

From Enquiry to Delivery

Seven steps, each with a decision that belongs to it. Nothing is left to be discovered at assembly.

Drawing reviewBundle drawing, tube schedule and tubesheet layout are read together, and any conflict between them is raised before quotation.
Material selectionBase tube alloy is fixed against the process stream; fin material is fixed against the outside environment.
Tube productionBare tube is rolled and cold drawn to the bundle size on 25 machines rather than substituted from stock.
Fin applicationThe fin geometry chosen at design stage is applied on the matching production line.
Tubesheet machiningThe plate is drilled to the same layout used to size the tubes, up to 5000 mm diameter.
InspectionHydro, eddy current, mechanical, chemical and dimensional checks before release.
Packing and exportBundles are packed for sea freight to the European, American and Gulf markets we ship to.
Products Involved

What This Solution Uses

Seamless stainless steel tubes stacked in the tube workshop Stainless Steel Tube Austenitic and super austenitic seamless tube and pipe to ASTM A213, A269 and A312 Tube outside diameter: 1/2" - 3" (12 mm - 76.2 mm) · Tube wall thickness: 0.02" - 0.5" (0.5 mm - 12.0 mm) Drilled tubesheet with the tube hole pattern machined to the bundle layout Tubesheet Drilled tube plate up to 5000 mm diameter and 750 mm thick Maximum outside diameter: 5000 mm · Maximum thickness: 750 mm G type embedded fin tube with the fin rolled into a groove in the base tube "G" Embedded Fin Tube Fin strip rolled into a machined groove in the tube wall for permanent metal-to-metal contact Base tube diameter: 16 mm - 80 mm · Base tube wall thickness: 1.65 mm - 4.0 mm Integral low fin tube with the fin rolled from the tube wall Low Fin Tube Integral low fin rolled from the tube wall itself, for shell and tube exchangers Base tube diameter: 12.7 mm - 31.8 mm · Base tube wall thickness: 1.65 mm - 3.0 mm
Capability Behind It

What Sits Behind the Promise

  • 25 rolling and cold drawing machines in the seamless tube workshop
  • 23 fin machines and lines across eight fin geometries
  • Tubesheets machined to 5000 mm outside diameter and 750 mm thickness
  • Hydro, eddy current, mechanical, chemical and dimensional testing in house
  • ISO 9001:2015, CE certificate, Production licence for pressure pipe
Machined tube plate with grooved tube holes
Tubesheet machined to the same drawing that sized the tubes.
FAQ

Heat Exchanger Bundle Supply Questions

Can you supply tube and tubesheet on one order?

Yes. Both are produced against the same bundle drawing, which is the point of the route.

What do you need to start?

The bundle drawing, the tube schedule and the tubesheet layout. If they disagree with each other we raise it before quoting.

Do you assemble the bundle?

We supply the tube, the finned tube and the drilled tube plate. Bundle assembly stays with the fabricator.

How is the shipment packed?

Bundles are packed for sea freight to the destination port you nominate.

Start With the Drawing

Send the bundle drawing, the process data or the tube schedule. The first thing you get back is a list of what is missing, not an invoice.
