Custom Printed 58x40 mm Self Adhesive Direct Thermal Scale Labels
A 58 x 40 mm direct thermal scale label printed with your brand colour and logo, waterproof, BPA-free, and wound 500 to 10,000 pieces per roll to suit counter scales and e-commerce packing stations.
- Product size58 x 40 mm, other sizes on request
- Popular sizes50x25, 60x40, 58x40, 58x60, 80x50, 80x60 mm or custom
- Material70 g thermal paper + hot melt adhesive + 60 g white glassine liner
- FacestockThermal paper with a thermal protective top coating
- AdhesiveHot melt adhesive or water based acrylic
- LinerWhite glassine
- Core1 in, 1.5 in or 3 in
- Pieces per roll500-10,000 pieces per roll or custom
- ColourWhite, custom colour or OEM printed
- FeatureWaterproof, oil resistant, scratch resistant, BPA free
- Industrial useShipping, food, medicine
- Brand nameNP-Label
- Custom orderAccepted
Free samples ship in 2 to 3 days. Tell us the printer model and the surface you are labelling and we will confirm the specification before you order.
What This Product Does Better
Scale prints stay readable at the till
The thermal protective top coat resists water, oil and plasticiser, so a weighed price label survives a wet chiller and a greasy hand without the barcode washing out.
Your brand travels with the parcel
Pre-printed colour and logo turn a functional scale label into packaging. The variable weight and price area stays blank for the thermal head.
Roll lengths matched to how you work
500 pieces for a slow counter, 10,000 for a packing line. Fewer roll changes on the busy station, less dead stock on the quiet one.
BPA free on the record
The thermal coating is BPA free, which is the first question a European or North American retail buyer asks about any receipt or scale stock.
What Goes Wrong Without It
- Printed scale labels ordered from a general print shop come back with the wrong gap or the wrong winding direction and jam the scale printer.
- Uncoated thermal facestock fades in the chiller, and the price label is unreadable before the product is sold.
- Ordering blank labels plus a separate sticker for branding doubles the handling at the packing bench.
Where It Is Used
- Supermarket and deli counter scales
- Fresh food and ready meal weighing and pricing
- E-commerce order picking and despatch
- Pharmacy dispensing labels
- Small business and boutique packing stations
Who Buys This Item
Supermarket chains, fresh food packers, e-commerce sellers running their own despatch, and distributors supplying scale labels to local retailers.
How It Compares With the Alternatives
Against a plain blank thermal label of the same size, this item adds pre-printed colour and logo at the cost of a one-time plate and a minimum run. Against a thermal transfer label, it needs no ribbon and is cheaper per label, but the image life is shorter and it will darken under sustained heat, so it suits retail turnover rather than long-term archive labelling.
How It Is Made and Checked
Coating, printing, slitting and die-cutting run on more than 30 production lines across two factories, producing around one million square metres of material a week.
Ribbon coating workshop
The ZHIYE ribbon coating workshop. Coating and slitting in the same building means a ribbon width and ink side can be built to a customer's printer rather than picked from stock.
Ribbon slitting
Jumbo ribbon stock being slit to finished widths. 30 mm to 110 mm and 30 m to 900 m are all cut to order on the same line.
Coating line
Adhesive coating on the label laminate line. Controlling the coat weight here is what makes the published peel adhesion figures repeatable.
Certification. High-Tech Enterprise, ISO 9001, ISO 14001, SGS, RoHS, BPA Free, FSC. The company is certified as a High-Tech Enterprise and holds multiple patents including one invention patent. Documentation applicable to this item is supplied with the shipment on request.
Getting It Right on the First Roll
Load with the coated (printable) side facing the thermal head; the coated side darkens when scratched with a fingernail.
Set the printer to direct thermal mode and calibrate on the gap sensor before the first batch.
Store rolls at 23 +/- 2 degrees C and 50 +/- 5 percent RH, away from solvents, plasticisers and direct sunlight.
Apply above 10 degrees C so the hot melt adhesive wets the surface properly.
What Can Be Changed to Order
Size and shape
Any size, and square, rectangle, round or oval dies. Ribbons are slit from 30 mm to 110 mm and 30 m to 900 m.
Material and adhesive
Paper, BOPP, PET and PE facestocks with hot melt, acrylic, removable or freezer adhesive.
Print and colour
CMYK, Pantone, full colour, transparent, gold and silver, by offset, flexo, screen, digital, inkjet or thermal transfer.
Core and winding
1 in, 1.5 in and 3 in label cores; 0.5 in and 1 in ribbon cores; piece counts and winding direction set to your printer.
Branding
Printed logo on the product, your design on the carton, or neutral packing with no supplier name.
Documentation
ISO 9001, ISO 14001, RoHS, SGS, FSC, BPA free and MSDS paperwork supplied where the product is covered.
Custom Printed 58x40 mm Self Adhesive Direct Thermal Scale L FAQ
Straight answers to the questions buyers ask before a first order.
Can you print our logo in a specific brand colour?
Yes. Custom material, size, colour and design are all available, and the label is supplied under the NP-Label brand or with no branding at all. Send artwork or an original sample and the design service is free.
How many labels come on one roll?
Between 500 and 10,000 pieces per roll, or a custom count. Core sizes are 1 in, 1.5 in and 3 in, so the roll can be matched to the printer you already use.
Will the print survive a wet or oily environment?
The facestock has a thermal protective coating with water, oil, plasticiser, scratch and weather resistance, which is why it is used for fresh food, shipping and medicine labels.
Is the paper BPA free?
Yes. The thermal coating used on this label is BPA free.
Can we get a sample before ordering?
Yes. Free samples are offered so you can test print quality and adhesion on your own printer and your own packaging before committing to a run.
