7 models
Variable Frequency Drives
Vector and V/F drives from 0.75 kW to 710 kW — compact OEM units, high-power vector platforms, distributed IP65 drives and active front ends that return braking energy to the grid.
The range splits by what the machine demands. BR100 is the mini drive for OEM machinery where panel space decides the design: same output in 30% less volume, with a fully sealed independent air duct that keeps dust out of the electronics. BR110 scales the same current-vector approach to 400 kW with the braking unit built in.
AD1000PLUS runs a dedicated 32-bit motor DSP to 710 kW at 380 V and 630 kW at 690 V, driving induction, built-in PM and surface-mount PM motors with 3% torque accuracy. AD1000-AFE adds PWM IGBT rectification for true four-quadrant operation, feeding a crane or elevator's inertial energy back into the grid at a power factor near 1.
FD500 moves the drive out of the cabinet altogether: IP65, mounted at the motor, coordinating over ModbusRTU, CanLink, PROFINET, PROFIBUS-DP or ASI. FS200 and FS300 are pump-specific, with constant-pressure PID control and IP54 bodies.
Models in this range
FD500 Distributed Inverter
An IP65 drive that mounts beside the motor instead of in a central cabinet, cutting motor cable runs and the EMI that comes with them.
AD1000-AFE Four-Quadrant Inverter
An active front end that feeds braking energy back to the grid at a power factor close to 1, for the elevators, cranes and high-inertia loads that…
AD1000PLUS High-Performance Vector Inverter
A 32-bit motor DSP platform reaching 710 kW at 380 V and 630 kW at 690 V, driving induction, built-in and surface-mount permanent magnet motors from…
FS200 Series Intelligent Pump AC Drive
A back-mounted 220 V constant-pressure drive for small pumps, IP54 rated, sized to go on the pump rather than into a panel.
FS300 Series Intelligent Pump AC Drive
A dual-mode pump drive: constant-pressure supply or straight frequency modulation, switchable, running both permanent magnet and asynchronous pump…
BR100 Variable Frequency Drive
A mini AC drive that puts open-loop vector performance into a body 30% smaller than comparable output, with a fully sealed heat dissipation duct.
BR110 Universal High-Performance Vector Inverter
A 0.75–400 kW current-vector drive with a built-in braking unit and RS485 MODBUS as standard, covering general industrial automation from one series.
Where this range is used
Energy and Power
VFDs in power systems cut energy use by 20–50% through boiler feed pump and fan speed control, renewable grid …
Steel Mill Plant
Rolling mills, blast furnace blowers and dust removal fans under VFD control — 20–40% lower motor energy consu…
Manufacturing and Industrial
Conveyors, robotic arms, pump and fan systems and heavy machinery under VFD control — with 30–50% energy savin…
Frequently Asked Questions
Which series should I quote for a general machine build?
BR100 below 11 kW where size dominates, BR110 to 400 kW for general industrial duty, AD1000PLUS above that or where PM motors and torque accuracy matter.
Do any of these handle regenerative loads?
AD1000-AFE is the four-quadrant unit. It feeds inertial energy back to the grid rather than burning it in a braking resistor.
What fieldbuses are supported?
RS485 MODBUS is standard on BR110 and BR110-P. FD500 adds ModbusRTU, CanLink, PROFINET, PROFIBUS-DP and ASI.
What supply voltage tolerance do these drives accept?
Typically ±15%. BR100 uses a wide voltage design covering 220 V/380 V/480 V at -15% to +10%.
