Five trimless models for plaster-in ceilings, where the fitting finishes flush with no visible ring.
The borderless build is specified when the ceiling plane has to read as continuous — hotel corridors, gallery ceilings, high-end residential. It needs an accurate cut and a plasterer on site, which is why it is normally a new-build rather than a refurbishment choice.
WA01-95-N is 125 mm across the body on a Ø95 mm cut-out, WA01-55-N is 82 mm on a Ø55 mm cut-out. The extra material is the mounting flange that sits above the plasterboard, so check the plenum clearance before specifying.
7 W to 30 W with 15°, 24°, 36° and 50° beams, on the 1313-08 and 1616-11 COB modules — the difference against the Circular Border series is the trim, not the light.
| Models in range | 5 |
|---|---|
| Wattage options | 10W, 12W, 25W, 30W, 7W |
| Cut-out sizes | 55, 65, 75, 85, 95 |
| Beam angles | 15/24/36/50°, 15/24/36/50°Match COB:1616-11 |
| Build options | Beam angle, reflector finish, housing colour, chip holder |
| Sample lead time | Normally 7 days |
Not cleanly. The trimless build assumes the ceiling is skimmed around the flange; for an existing hole the Circular Border series is the correct alternative.
WA01-95-N at 116 mm, on a Ø95 mm cut-out.
Tell us the models, the quantities and the finish, and we will send pricing and a sample plan.
