FT0804 RF Weather Station
The FT0804 RF Weather Station is a complete indoor console and outdoor sensor system that measures temperature and humidity both indoors and outdoors, displays barometric pressure and weather forecast, and sends updates every 60 seconds over a 433MHz link. It supports up to eight
What This Model Is For
The FT0804 RF Weather Station is a complete indoor console and outdoor sensor system that measures temperature and humidity both indoors and outdoors, displays barometric pressure and weather forecast, and sends updates every 60 seconds over a 433MHz link. It supports up to eight additional thermo-hygrometer sensors, making it suitable for monitoring multiple zones within a building or garden. The console features a large 7-inch LCD with blue backlight and includes alarm functions, dew point display, and min/max recording for daily analysis. It operates on four AAA batteries for the console and two AAA batteries for the outdoor sensor, with a 5.9V power adapter included for continuous operation.
- One console manages up to eight outdoor sensors, reducing the need for multiple displays
- 60-second transmission interval provides timely updates without overwhelming the RF channel
- 433MHz link reaches 100 meters in open air, suitable for most residential and light commercial sites
- Blue backlight improves readability in low-light conditions
- Supports both Celsius and Fahrenheit, with automatic unit switching on the console
Product Images
Where It Is Used
- Home weather monitoring for gardeners and homeowners tracking indoor and outdoor conditions
- Small retail stores or showrooms needing a visible, easy-to-read weather display
- Greenhouse and nursery operations monitoring microclimate across multiple zones
- Small office or warehouse environments tracking humidity and temperature for equipment safety
- Distributors selling a complete weather station with a single SKU and no extra wiring
Who It Is For
- Consumer electronics brands launching an own-label weather station without RF or firmware development
- Distributors needing a ready-to-sell weather station with built-in alarm and forecast features
- Agricultural suppliers bundling sensors with irrigation or climate control systems
- HVAC and building services integrators monitoring indoor air quality across zones
- Marine and leisure equipment suppliers adding a weather display to boat cabins or pool houses
Problems It Solves
- Brands that lack in-house RF or firmware teams but need a working weather station
- Buyers whose current sensor fails after one season due to poor sealing or battery drain
- Sites where a wired sensor is not feasible due to cabling or power access issues
- Projects needing multiple sensor points but only one display and no complex setup
- Users who need a clear, large display with alarm functions for daily monitoring
Technical Features
- Indoor and outdoor temperature and humidity displayed in real time
- Barometric pressure reading from 300 to 1100 hPa with forecast indication
- Min/max temperature and humidity records with daily reset
- Dew point calculation and alarm for CH1 sensor
- Temperature and humidity calibration function on the console
- Transmission every 60 seconds over 433MHz RF
- Supports up to eight thermo-hygrometer sensors on the same console
- 7-inch LCD with blue backlight for improved visibility
- Freestanding or wall-mountable console with alarm and calendar functions
- Outdoor sensor uses two AAA batteries with a power adapter included for the console
Specifications
Values taken from our own product documentation. Anything we cannot verify is marked rather than estimated.
| Indoor Temperature Range | 0 to 60 degrees C |
|---|---|
| Outdoor Temperature Range | -40 to 60 degrees C |
| Temperature Accuracy | plus or minus 1 degree C |
| Barometric Pressure Range | 300 to 1100 hPa |
| Barometric Accuracy | plus or minus 3 hPa |
| Humidity Range | 10 to 99 percent RH |
| Humidity Accuracy | plus or minus 5 percent |
| Transmission Frequency | 433 MHz |
| Transmission Range | 100 meters in open area (300 feet) |
| Transmission Interval | 60 seconds |
| Console Power | 4 x AAA alkaline batteries (not included) |
| Sensor Power | 2 x AAA alkaline batteries (not included) |
| Power Adapter | 5.9V, 0.5A (included) |
| Console Dimensions | 152 x 84 x 25 mm (H x W x D) |
| Sensor Dimensions | 45 x 110 x 21 mm (H x W x D) |
| LCD Size | 109 x 129 mm (7 inch) |
Materials and Construction
- Moulded plastic housing for the console and outdoor sensor
- Weather sealed outdoor enclosure for the sensor body
- Battery compartment sized for 2 x AAA cells in the outdoor sensor
How It Is Made
Console and sensor sub-assemblies are assembled on our own production lines
Outdoor sensor housings are sealed and tested on rainfall and waterproof test equipment
Each unit undergoes final ageing test before packing
Assembly includes soldering and component insertion on dedicated lines
Quality Control
- Rainfall and waterproof testing on the assembled outdoor sensor
- Constant temperature and humidity chamber runs to verify -40 to +60 degrees C performance
- Vibration testing to simulate transport and site loading
- Smog ageing to assess long-term housing and seal integrity
- Final ageing test on every unit before packaging
Customisation Options
- Own-label printing on console and sensor housing
- Retail packaging with customer branding
- Manual and quick start guide in the destination language
- Alternative battery configurations on request
Compared With the Alternatives
vs Separate indoor and outdoor units with no console integration
One console reduces the number of displays and simplifies setup, but limits the number of sensors to eight
vs Wi-Fi weather stations requiring a router and app
433MHz is simpler and more reliable in areas with weak Wi-Fi; no app dependency
vs LoRa-based sensors for long-range sites
433MHz is sufficient for a single property; LoRa is better for fields or large campuses
Use Guide
- Place the console in a central indoor location, away from direct sunlight and heat sources
- Mount the outdoor sensor at least 1.5 meters above ground, clear of obstructions
- Align the sensor away from walls and metal surfaces to avoid interference
- Insert batteries into the console and sensor before first use, and connect the power adapter if needed
- Calibrate temperature, humidity, and barometer on the console using known reference values
- Check battery levels monthly and replace when low, especially in cold weather
FT0804 RF Weather Station Questions
What is the real range between the console and outdoor sensor
100 meters in open air. Through walls, foliage, or a roof, expect around 30 meters, which covers most homes and gardens.
How often does it update the readings
Every 60 seconds, which balances timely updates with battery life and RF stability.
Can I use the power adapter with the outdoor sensor
No. The power adapter is only for the console. The outdoor sensor runs on two AAA batteries.
How many sensors can the console support
The console supports up to eight thermo-hygrometer sensors, including the included FT007TH.
What certifications does it carry
TBC. Ask us for the current certificate set for your destination market before you place the order.
What is the lead time and minimum order
Tell us the quantity and target ship date and we will confirm both by email. Lead time depends on whether own-label printing and packaging are involved.
