HE010-007 Check Valve
HE010-007 is a wafer type check valve designed for automatic non-return service in water, low-pressure industrial and heating pipelines. It operates without manual input, opening under forward flow and closing by spring force and reverse flow. The valve body clamps between two pipe flanges, eliminating the need for separate flanges and reducing installation space. It is part of a range covering DN10 to DN2600 and 0.05 to 4.0 MPa, with over 600 models available in-house.
| Model Code | HE010-007 |
|---|---|
| Product Type | Check Valve |
| Category | Wafer Type Dual Plate Check Valves |
| Manufacturer | Tianjin MIC Valve Co., Ltd. |
| Size and Pressure Rating | Confirmed on quotation |
| Certification | ISO 9001 and ISO 14001 certified plant |
| Model | HE010-007 |
| Valve Type | Wafer type check valve |
| Operation | Automatic non-return, spring-assisted closure |
| Connection | Wafer, clamped between pipe flanges |
| Series | HE010 wafer check valve series |
| Nominal Diameter Range | DN10 to DN2600 mm |
| Nominal Pressure Range | 0.05 to 4.0 MPa |
What This Model Gives You
- Automatic operation requires no handle, actuator or operator, reducing maintenance and control complexity
- Wafer body clamps between existing flanges, saving cost and space compared to flanged or lug types
- Spring-assisted closure ensures rapid shut-off during reverse flow, preventing backflow and water hammer
- Compact face-to-face length allows installation in tight spaces where larger valves would not fit
- Bidirectional flow protection is built into the design, with no need for orientation during installation
- Part of a factory programme certified to ISO 9001 and ISO 14001 for consistent quality and environmental control
Problems It Removes
- Manual isolation valves require operators and are not suitable for automatic protection in unattended systems
- Lug or flanged check valves add weight and length to the pipeline, increasing material and installation cost
- Inconsistent closure speed in older check valves leads to water hammer and pipe stress
- Lack of standardisation across check valve models makes spare parts hard to stock
- Buyers need a single supplier who can cover both small and large diameters in the same product family
Where It Is Installed
- Preventing backflow in pump discharge lines where power failure could cause reverse flow
- Protecting water supply systems in municipal distribution networks from contamination during pressure drops
- Maintaining flow direction in heating and cooling circuits in HVAC systems with multiple zones
- Isolating sections of process lines in chemical and pharmaceutical plants during batch changes
- Supporting sewage treatment plant pump systems where flow reversal must be avoided during pump shutdown
Buyers It Suits
- Water utility engineers specifying non-return protection in distribution and pumping stations
- HVAC contractors installing check valves in heating and cooling loops with space constraints
- Pump and skid system builders needing automatic isolation in compact packages
- Industrial plant maintenance teams replacing legacy check valves with a standardised, low-maintenance option
- EPC firms sourcing a range of check valves from DN10 to DN2600 under one supplier
How It Is Built
- Wafer body clamped between two pipe flanges using through bolts
- Automatic non-return operation with spring-assisted closure on reverse flow
- Disc opens under forward flow and closes when flow reverses or stops
- No handle, actuator or gearbox required; fully self-operating
- Part of the HE010 wafer check valve series covering DN10 to DN2600
- Designed for use in water, low-pressure industrial and heating systems
Material Selection
- Body, disc and spring materials are confirmed per order based on the medium and operating temperature
- Seat and internal components are selected from variants offered across the HE010 series
- Material certificates are issued with the order upon request
How It Is Made
- Body casting inspected and machined on in-house fine machining equipment
- Disc and spring assembled as a matched closure unit
- Assembly of disc, spring and seat into the body with alignment checked
- Valve tested for automatic operation and closure under reverse flow
- Marked, wrapped and crated for container shipment from Tianjin
How It Is Checked
- Dimensional check of body face-to-face length and flange bolt pattern before assembly
- Flow direction and closure performance tested on assembled valves
- Spring force and closure speed verified on a sample basis
- Testing carried out on the 10 sets of imported inspection and testing equipment
- Records maintained under the ISO 9001 quality management system
Certificates Issued With This Valve
- ISO 9001 quality management system certification
- ISO 14001 environmental management system certification
Certification statements are limited to the management system certificates the factory actually holds. Product-level approvals for your market are confirmed before order.
What Can Be Changed
- Disc and spring variant selected for the medium and temperature on the buyer's line
- Flange drilling matched to the standard used on the buyer's pipework
- Private label marking and packing available on OEM orders
- Mixed-diameter orders combined with other valves in one container
- Material combination confirmed during quotation
How It Compares With the Alternatives
| Lug type check valve | The lug body allows end-of-line service and can be installed with one flange; the wafer body requires flanges on both sides |
|---|---|
| Flanged check valve | The flanged version adds weight and length; the wafer body is shorter and lighter for the same duty |
| Spring-loaded gate valve | The gate valve offers a full bore but is heavier, longer and more expensive than the wafer check valve |
| Ball check valve | The ball check valve has a smaller footprint but may not handle high flow rates or debris as well as the disc-type wafer check valve |
Installing and Operating This Valve
- Confirm the flange standard and bolt pattern on both pipe flanges before ordering
- Install the valve with the arrow on the body pointing in the direction of forward flow
- Do not use the wafer body as a pipe end closure during pressure testing
- Ensure the disc is free to move and the spring is not compressed during installation
- Avoid installing in horizontal runs with debris-prone media without a strainer upstream
- Inspect the valve periodically in systems where it remains inactive for long periods
