Vitrified Bond CBN Internal Grinding Wheel
Bore, channel and super finishing grinding for bearings, C.V. joints, nozzles and compressors.
Product Overview
Vitrified Bond CBN Internal Grinding Wheel
Bore, channel and super finishing grinding for bearings, C.V. joints, nozzles and compressors.
Application
- Bore grinding
- Internal & external channel grinding
- Internal & external channel super finishing
- C.V. Joint cage grinding
- Nozzle grinding
- Upper & bottom bearing internal grinding
- Piston sleeve internal grinding
- Cylinder internal grinding
Specifications
Shapes And Dimensions
Shape codes and dimension ranges as published in the Bello printed catalogue. Other sizes on request.
| Shape | Specification (mm) |
|---|---|
| 1A8 | 13*20*6 |
| 1A1W | 15*4.5*M8 |
| 1A1W | 22.5*13*M8 |
| 1A1W | 16*28*M6 |
| 1F1W | 25*4.3*M10 (R2.25) |
| HMF | 40*8*10*20 |
| Shape | Specification (mm) |
|---|---|
| 1F1W | 25*4.3*M10 (R2.25) |
| HMF | 40*8*10*20 |
| Shape | Specification (mm) |
|---|---|
| 1B8W | Φ3.45*8.99T–60° –M2 |
| 1A8W | Φ2.0*5.7T*16L–120° –M3*0.5 |
| 1A8W | Φ10.78*4.8T / 8.2*31.1*1.3–M4/4.5 |
| 1A8 | Φ4.5*15T*2.4H |
| Shape | Specification (mm) |
|---|---|
| 1A1W | 15.5*50*M10 |
| 1A1W | 8.3*16*M12 |
| 1A1W | 22.5*37*M20 |
| 1A1W | 51*52*M18 |
| 1A8 | 15.4*48*10 |
