Optical Profile Grinding Wheel
High speed profile grinding of precise mould & die, punches, cutting tools and instruments.
Product Overview
Optical Profile Grinding Wheel
High speed profile grinding of precise mould & die, punches, cutting tools and instruments.
Feature & Advantage
- High speed grinding
- Precise grinding
- Excellent shape-maintenance
- Long tool life
Application
- Precise mould & die
- Precise punch
- Precise cutting tool
- Precise instrument
Specifications
Shapes And Dimensions
Shape codes and dimension ranges as published in the Bello printed catalogue. Other sizes on request.
| D (mm) | U (mm) | H (mm) | X (mm) |
|---|---|---|---|
| 75 / 85 / 100 | 0.4 / 0.5 / 0.6 / 0.9 / 1.0 | 22.25 / 24 | 3 |
| D (mm) | W (mm) | V (mm) | T (mm) |
|---|---|---|---|
| 65 / 75 / 85 / 100 / 125 | 5 / 8 / 12 | 10 / 12 / 15 | 6 |
| D (mm) | T (mm) | H (mm) | W (mm) |
|---|---|---|---|
| 65 / 75 / 85 / 100 / 125 | 6 | 22 / 22.25 / 24 | 8 / 12 |
Related Products
Also Used In Tool & Mould Application
Centerless Grinding Wheel
Rough, semi-fine and fine external grinding of tungsten carbide, ceramic, magnetic material, stainless steel bar and PCD/PCBN composite.
View Product →
Cutting Off & Slotting Wheel
Precise cutting and slotting of semiconductor, optical glass, quartz, magnetic material and cutting tool blanks.
View Product →
Diamond Wheel For CNC Grinder
Cemented carbide, cermet and HSS tool grinding on ANCA, WALTER and ROLLOMATIC machines.
View Product →
For PCD & PCBN Cutting Tools
Vitrified bond wheels for PCD and PCBN cutting tools on EWAG and Coborn grinders.
View Product →FAQ
Frequently Asked Questions
What is the Optical Profile Grinding Wheel used for?
Precise mould & die; Precise punch; Precise cutting tool; Precise instrument.
What are the advantages of the Optical Profile Grinding Wheel?
High speed grinding; Precise grinding; Excellent shape-maintenance; Long tool life.
Which shapes are available?
75 / 85 / 100, 65 / 75 / 85 / 100 / 125. Dimension ranges are listed in the specification table above.
Which application groups is it listed under?
Tool & Mould Application.
How do I request a quotation?
Email [email protected] or call +86-370-7981119.
Need The Optical Profile Grinding Wheel To A Drawing?
Send us your wheel specification, the workpiece material and the machine model.
