DIN 42530 1kV 2000A Transformer Bushing

• Home
• Products
• Low Voltage Transformer Bushings
• DIN 42530 1kV 2000A Transformer Bushing

Product Overview

A DIN 42530 low voltage transformer bushing for power transformers, rated 1 to 3 kV at 2000 A. The DIN 42530 table gives 75 mm creepage and a 1.29 kg weight at this rating, against 50 mm and 0.26 kg at 250 A. Construction is a porcelain insulator with copper fittings, shipped in export cartons on wooden pallets.

• DIN 42530

Why Buyers Choose This Part

• 2000 A conductor path for high output low voltage terminals
• 75 mm creepage from 630 A upward, published per current rating
• 1.29 kg at this rating, light enough for a crowded terminal board
• Copper fittings throughout the current path

Where It Is Used

• Power transformer low voltage terminals at 2000 A
• Larger distribution transformers with high LV output
• Transformer manufacture standardising on DIN 42530
• Replacement during overhaul of higher-rated units

Who It Suits

• Power and distribution transformer manufacturers
• Service workshops handling higher-rated transformers
• Distributors stocking the full DIN 42530 current range

What Goes Wrong Without The Right Part

• Terminal heating on high current LV connections
• Selecting creepage and weight across the DIN 42530 range without data
• Transit damage to bushings shipped without proper packing
• One part number covering both 1 kV and 3 kV terminal boards

How It Is Built

• DIN 42530 at 1 to 3 kV and 2000 A
• 75 mm creepage distance at this rating
• 1.29 kg weight
• Porcelain insulator with copper fittings
• Export carton and wooden pallet transport packing
• Made in China

Published Figures For This Product

Every value below comes from the manufacturer data for this item. Figures not listed are confirmed against the drawing before an order is placed.

Creepage Distance At This Rating	75 mm
Weight	1.29 kg
Creepage Distance	50 mm

Materials

• Porcelain insulator
• Copper fittings

Process

• Forming
• Glazing
• Firing
• Copper fitting assembly
• Routine electrical test

Testing

• Creepage checked against the 75 mm figure
• Weight verified against the 1.29 kg reference
• Conductor path resistance check at the 2000 A rating

Certification

• Manufactured to DIN 42530
• ISO 9001 quality management system

Customisation Options

• Special lengths or connection types to customer specification
• Other DIN 42530 ratings from 250 A to 3150 A
• OEM and ODM supply

How It Compares

DIN 42530 1/1000 A	Same 75 mm creepage but 1.04 kg against 1.29 kg, with a smaller conductor path. Match the bushing to the LV output current.
DIN 42530 1/3150 A	The 3150 A version keeps 75 mm creepage but rises to 2.05 kg. Creepage stops changing above 630 A, only the conductor grows.

Before You Order And After It Arrives

• Size the LV connection hardware for the full 2000 A rating
• Confirm the terminal board takes the DIN 42530 pattern
• Keep the pallet packing intact until installation
• Check copper fitting faces are clean before making the joint
