What This Engine Is Built For
The Cummins 6LTAA8.9-GM215 is a 6-cylinder in-line marine diesel engine of 8.9 L with a 114 * 145 mm bore and stroke supplied by MEP Power as a complete assembly. It is rated at 215 kW (288 HP) at 1800 rpm. The engine is turbocharged/charge air cooled and water cooled, with a Bosch P7100 Pump/RQV-K Governor fuel system. It is built at the Dongfeng Cummins Plant 6LTAA8.9-GM215 and carries CCS/IMO Certificates. Typical duty is propulsion and auxiliary duty on workboats, fishing vessels, tugs and barges; dry weight with flywheel and alternator is 650 Kg and the overall envelope is 1149mm*799mm*1022mm.
Key Benefits
- Delivers 215 kW (288 HP) at 1800 rpm from 8.9 L as a factory-rated assembly.
- Turbocharged/Charge Air Cooled induction with water cooling keeps charge temperature under control in continuous duty.
- Supplied to CCS/IMO Certificates, so the unit can be registered in markets that require it.
- Dry weight 650 Kg and envelope 1149mm*799mm*1022mm are published so the installation can be checked before ordering.
- Published fuel consumption of ≤ 245 g/kW.hr 6LTAA8.9-GM215 makes running cost predictable.
- Starts without auxiliary aids down to -12℃.
Application Scenarios
- Main propulsion in a steel workboat
- Auxiliary and deck machinery drive
- Fishing vessel repower
- Harbour tug and pilot boat service
Who It Is For
- Shipyards repowering workboats and fishing vessels
- Boat owners replacing a worn main engine without changing the engine bed
- Marine service yards that keep exchange engines on the shelf
- Fleet operators standardising on one Cummins family across several hulls
Problems It Solves
- A vessel out of service earns nothing, and a mismatched replacement engine means new mounts, new couplings and weeks of yard time.
- Marine duty punishes engines that were never cooled for sea water service.
- Spare parts for grey-import engines are hard to identify years later.
- Identifying the right 6LTAA8.9-GM215 variant from a serial number takes experience; MEP Power checks the configuration before quoting.
Specification As Published
Values below are the published data for this unit. Where a figure is not listed it was not stated by the source data sheet; ask and we will confirm before you order.
| Model | 6LTAA8.9-GM215 |
| Type | 6 Cylinders in Line |
| Displacement | 8.9 L |
| Bore x Stroke | 114 * 145 |
| Net Weight (with flywheel and alternator) | 650 Kg |
| Overall Dimension | 1149mm*799mm*1022mm |
| Engine Configuration Number | D563014MX03 |
| Manufacturing Plant | Dongfeng Cummins Plant 6LTAA8.9-GM215 |
| Rated Power/Speed | 215 kW/288HP @ 1800 rpm |
| Standby Power | 237 kW/318HP @ 1800 rpm |
| Continuous Output/Speed | 175 kW/235HP @ 1500 rpm |
| Low Idle Speed | 650-750 rpm |
| Fuel Consumption (running speed) | ≤ 245 g/kW.hr 6LTAA8.9-GM215 |
| Certification | CCS/IMO Certificates |
| Aspiration | Turbocharged/Charge Air Cooled |
| Fuel System | Bosch P7100 Pump/RQV-K Governor |
| Compression Ratio | 16.6:1 Starting Method: Electrical/Air Start (12V/24V) |
| Lowest Starting Temp (without auxiliary system) | -12℃ |
| Engine Cooling Fluid Volume | 11.1 L |
| Firing Order | 1-5-3-6-2-4 |
| Cooling Method | Water Cooled |
| Rated Power | 215 kW (288HP) |
| Rated Speed | 1800 rpm |
| Cylinders | 6 Cylinders in-line |
| Prime Power | 215 kW/288HP |
Technical Features
- Cylinders: 6 Cylinders in Line
- Displacement: 8.9 L
- Bore and stroke: 114 * 145
- Aspiration: Turbocharged/Charge Air Cooled
- Fuel system: Bosch P7100 Pump/RQV-K Governor
- Compression ratio: 16.6:1 Starting Method: Electrical/Air Start (12V/24V)
- Firing order: 1-5-3-6-2-4
- Coolant capacity: 11.1 L
Quality Control
- Every engine is inspected by the MEP Power inspection team before it leaves the warehouse
- Engine, configuration and serial numbers are recorded and photographed for the buyer
- Genuine and OEM units are quoted separately so the buyer knows exactly what is supplied
- Warranty on genuine and OEM new engines and generator sets is one year or 1000 hours, whichever comes first; parts and repair labour are covered for quality faults inside that period.
Use and Installation Guide
- Quote the model 6LTAA8.9-GM215 and the engine configuration number D563014MX03 when ordering so the correct variant is supplied.
- Check the gearbox reduction ratio and propeller match before ordering
- Confirm raw-water or keel cooling to suit the hull
- Commission with the exhaust system and sea water pump connected as supplied
- Keep the warranty terms in mind: one year or 1000 hours, whichever comes first.
Customisation Options
- OEM and ODM builds, including your logo and company name on the unit
- Cummins engine customisation and modification to your requirement
- Mining and special explosion-proof builds
- Genuine or OEM parts specified on the quotation
How It Compares
| Compared with | What to consider |
|---|---|
| A rebuilt or used engine of the same rating | A rebuilt unit may show the same 215 kW (288 HP) on paper, but its running history is unknown and the warranty rarely covers the whole engine. |
| A larger engine in the same 6LTAA8.9 range | Moving up a frame size adds weight, envelope and fuel burn; specify the next size up only if the duty cycle really needs the headroom. |
| A non-Cummins engine of similar output | Parts and service for Cummins families are available in most markets, which matters more over ten years than the purchase price on day one. |
6LTAA8.9-GM215 Questions
Is this 6LTAA8.9-GM215 a genuine Cummins engine
What power does the 6LTAA8.9-GM215 produce
What warranty comes with the engine
How do I confirm this is the right variant for my machine
How is the engine shipped and what payment terms apply
