RSL613

Home / RESUNYOU Brand TBR / Long and Regional Haul / RSL613

The tread pattern delivers high wear resistance and strong anti-side-skid performance, with good drainage and consistent handling across long hauls. It is available in 11R22.5, 11R24.5, 285/

Overview

The tread pattern delivers high wear resistance and strong anti-side-skid performance, with good drainage and consistent handling across long hauls. It is available in 11R22.5, 11R24.5, 285/75R24.5, and 295/75R22.5 sizes, all with 14 ply rating and suitable for 8.25 to 9.00 inch rims.

• ISO9001
• ISO/TS16949
• CCC
• E-mark
• DOT
• GSO/GCC
• SONCAP
• INMETRO
• NOM

What RSL613 Gives the Operator

High wear resistance extends casing life in high-mileage highway operations

Anti-side-skid tread design improves stability during cornering and braking

Good drainage performance reduces hydroplaning risk on wet highway surfaces

Consistent handling across steer and trailer positions enhances vehicle control

14 ply rating provides durability for sustained highway loads and long service cycles

Application Scenarios

• Long distance bus operations on paved highways with frequent stops and high daily mileage
• Light truck distribution fleets running on national trunk roads with mixed loading
• Trailer axles on regional hauls where consistent tread wear and low noise are required

Who It Is For

• Tyre importers stocking steer and trailer patterns for buses and light trucks
• Fleet operators replacing steer and trailer tyres on highway-running buses
• Distributors needing a cost-effective radial pattern for mixed container shipments

What It Is Meant To Fix

Steer tyres that wear unevenly due to poor lateral stability on long hauls

Trailer tyres that develop shoulder wear from poor load distribution and high speed

Tread patterns that fail to maintain grip on wet highways, increasing stopping distance

Short casing life leading to higher replacement frequency and cost per kilometre

Published Data For RSL613

These are the figures published for this product. Anything not listed here is confirmed in writing before an order.

Size
PR
Standard Rim
Load Index and Speed
Overall Dia mm
Section Width mm
Max Load kg Single/Dual
Max Pressure kPa	11R22.5	14	8.25	144/142M	1050	279	2800/2650	720	11R24.5	14	8.25	146/143M	1100	279	3000/2725	720	285/75R24.5	14	8.25	144/141L	1056	283	2800/2575	760	295/75R22.5	14	9.00	144/141L	1014	298	2800/2575	760

Technical Features

• High wear resistance tread compound for extended casing life
• Anti-side-skid tread design with lateral grooves for improved cornering stability
• Multiple circumferential and lateral grooves for effective water evacuation
• 14 ply rating casing suitable for sustained highway use and retreading
• Optimized tread pattern for steer and trailer axle positions on buses and light trucks

Customisation

• Container loading planned across sizes and patterns in one shipment
• Sidewall marking and labelling to suit the destination market on request

Quality Control

• X-ray inspection of the finished casing before packing
• Dynamic balance check on the production line
• Production under ISO9001 and ISO/TS16949 systems

How It Compares

• Compared with A premium European steer tyre Lower purchase price per casing, with a shorter proven mileage record in independent fleet testing

Getting the Most Out Of It

• Fit to steer or trailer axle positions only, not for drive axles
• Set cold pressure to the actual load carried, not the maximum listed on the sidewall
• Monitor pressure weekly to prevent shoulder wear from under inflation

Related Products

RTR331

RSL616

RSL615

RSL612

Industries That Use It

• Long Haul Freight
• Regional Distribution
• Bus and Coach

Related Guides

• Choosing Steer Drive and Trailer Patterns
• Load Index and Inflation Pressure Explained
• When to Replace a Truck Tyre

RSL613 Questions

11R22.5 and 11R24.5 carry 3000 kg single and 2725 kg dual at 720 kPa. 285/75R24.5 and 295/75R22.5 carry 2800 kg single and 2575 kg dual at 760 kPa.

The casing is built for retreading, though acceptance depends on the retreader and operating conditions. Confirm with your retreader before large volume commitment.

Resunyou products carry ISO9001, ISO/TS16949, CCC, E-mark, DOT, GSO/GCC, SONCAP, INMETRO and NOM approvals. Tell us your destination market and we will confirm which marking applies.

All sizes are 14 ply rating. 11R22.5 and 11R24.5 use 8.25 inch rims. 285/75R24.5 uses 8.25 inch rim. 295/75R22.5 uses 9.00 inch rim.

Yes. Truck tyres, car tyres, off the road tyres and wheels are routinely loaded into the same container. Send the sizes and quantities per size and we will plan the load.

Email [email protected] with the sizes and quantity you need. The email button on this page pre fills RSL613 in the subject line so the enquiry reaches the right desk.

Get Pricing For RSL613

Send the sizes and quantity per size. We will confirm availability, the approval marking for your market and a container plan.
