Screw Pin Chain Shackle D Type
Screw Pin Chain Shackle D Type is supplied by Kailipu as part of the Shackles family from Qingdao, and is quoted against the size, capacity and finish your requirement calls for.
39 shackle lines from 0.33 t to 300 t. G209 G210 G2130 G2150 and European Large D patterns, hot dip or electro galvanised, EN 10204 3.1 MTC on request
Specifications
| Capacity range | 80 kg to 8000 kg safe working load |
|---|---|
| Material | Carbon steel or stainless steel |
| Surface finish | Electric galvanized |
| Safety factor | 3:1 minimum |
| Size range | M5 to M50 |
| Working load limit at M5 | 80 kg |
| Working load limit at M50 | 8000 kg |
| Weight at M5 | 0.014 kg |
| Weight at M50 | 11.5 kg |
Specification values are taken from the supplier's published product data. Sizes and capacities outside the listed range are quoted on request.
Key features
- Threaded screw pin enables fast and secure connection without requiring a separate pin tool
- Drop forged carbon steel or stainless steel body provides high tensile strength and impact resistance
- Electric galvanized surface finish resists corrosion in humid and outdoor environments
- 3:1 safety factor ensures reliable performance under rated load conditions
Typical applications
- Rigging and lifting distributors building a complete shackle range under one brand
- Crane hire and lifting service companies replenishing bow and dee shackles across a fleet
- Marine and offshore outfitters needing hot dip finishes and large bow patterns for deck work
