Sandwich Panel Connector Butterfly Plate
Sandwich Panel Connector Butterfly Plate is supplied by Kailipu as part of the Precast Concrete Lifting Systems family from Qingdao, and is quoted against the size, capacity and finish your requirement calls for.
12 precast concrete lifting system components including U-shape, spherical head, and utility anchors with galvanized or custom finishes. EN 10204 3.1
Specifications
| Capacity range | 6T to 12T safe working load |
|---|---|
| Material | Forged alloy steel |
| Safety factor | 3:1 minimum breaking load to safe working load |
| Length range | 146mm to 203mm |
| Width Range | 100mm to 125mm |
| Surface finish | Plain finish electrogalvanized or hot-dip galvanized |
| Standards | Meets international safety and performance standards |
Specification values are taken from the supplier's published product data. Sizes and capacities outside the listed range are quoted on request.
Key features
- Forged alloy steel construction provides high tensile strength and impact resistance for structural integrity
- Butterfly plate shape ensures firm anchorage in both concrete layers and resists pull-out under load
- Maintains consistent spacing between inner and outer panels to preserve insulation performance
- Minimizes thermal bridging by reducing heat transfer across the connector body
Typical applications
- Precast concrete manufacturers building lifting sets for beams, panels, stairs and structural components
- Construction site supervisors managing lifting operations for precast elements on site
- Project engineers specifying lifting systems in precast detailing drawings
