Grade 80 Hooks

Forged Mild Steel Agricultural Hook

Forged Mild Steel Agricultural Hook is supplied by Kailipu as part of the Grade 80 Hooks family from Qingdao, and is quoted against the size, capacity and finish your requirement calls for.

20 Grade 80 hook lines in single and double designs, heat-treated alloy steel, powder coated finish, WLL stamped on bow, EN 10204 3.1 MTC on request.

Specifications

Capacity range	50mm to 120mm
Material	Forged mild steel
Surface finish	Yellow painted, other colors available on request
Working Load Limit	Permanently stamped on the body
Size 50Mm	Φ 8.5 B 34 E 13 L 56 mm weight 0.04 kg
Size 60Mm	Φ 9.5 B 41 E 16 L 70 mm weight 0.06 kg
Size 70Mm	Φ 11 B 45.5 E 13 L 80 mm weight 0.095 kg
Size 80Mm	Φ 11 B 54 E 17 L 90 mm weight 0.13 kg
Size 90Mm	Φ 12.5 B 58 E 18 L 102 mm weight 0.196 kg
Size 100Mm	Φ 12.5 B 62 E 19 L 114.5 mm weight 0.3 kg
Size 120Mm	Φ 15.5 B 62 E 20 L 118 mm weight 0.33 kg

Specification values are taken from the supplier's published product data. Sizes and capacities outside the listed range are quoted on request.
